Special power supply for Powerbox ultimate V2 XT60 CONNECTOR

specification

•         Output voltage: 12V
•         Loading: 0-10 amps
•         Max. Power: 120 watts
•         Input voltage range: 90-264V, connector size: 5.5*2.1mm or 5.5*2.5mm or XT60
•         Frequency: (47-63)Hz
•         Cord length: 150 cm / 5 feet
•         Regulated output with low ripple noise
•         Sealed / protected housing (moisture / dust cannot enter)
•         Safety agency requirements and EMI/EMS certification
•         Efficiency Level (ErP): VI
•         CE and FCC certificate acquired
•         Dimensions: 169 x 61 x 39 [mm]

Protections

• Over Current / Short Circuit Protection: The power supply will automatically protect any output to ground and automatic recovery when abnormal circuit faults disappear. An output short is defined as any output impedance less than 0.1 ohms.
• Over voltage: power will be automatically recovered when faults disappear
• Input protection: F1: 6.3A 250V fuse The power supply should be protected against over voltage and any abnormal condition
• No load protection The power supply is supplied without load operation to prevent the power supply and the system from being damaged.
• Protection class I, (ITU-T K.21 Surge 6KV on request)
